Ground Zero Hydrogen Series 12" FLAT Sub-Woofer

Ground Zero Hydrogen Series 12" FLAT Sub-Woofer

Regular price $499.99 USD
Regular price Sale price $499.99 USD
Sale Sold out
OHM

12″ high quality flat SPL subwoofer

                              Hydrogen Series

High-Grade Technology Products of the HYDROGEN series match with the demands of highly sophisticated customers.
Amazing performance, great sound quality and high SPL whenever required.
The subwoofers have been developed to handle a huge amount of input power reaching extremely high bass levels, to be used successfully even under competition conditions.
A matching 2-way component speaker system and a number of MINI amplifiers with compact dimensions for limited installation space complete this famous GROUND ZERO line-up.

                                                   1200 Watts SPL

12″ high quality flat SPL subwoofer with alumiunum cast basket

  • 12″ high quality flat SPL subwoofer
  • Klippel® optimized
  • Sandwich paper cone
  • Durable U-shape rubber surround
  • Solid aluminum cast basket
  • 63 mm / 2.5″ copper voice coil
  • 4-layer copper voice coil
  • Push terminal
Model High-Quality Flat SPL Subwoofer
Diameter 30 cm / 12″
Power handling (RMS/SPL) 700 / 1200 Watts
Impedance 2x 2 Ohms
Efficiency 88 dB
Power recommendation 500 – 1200 Watts
Voice coil 63 mm / 2.5″ Copper
Cone Sandwich paper
Max. Excursion (Xmax) 32 mm / 1.26″
Mounting Ø 284 mm / 11.18″
Mounting depth 118 mm / 4.65″
Resonance frequency (Fs) 21 Hz
Overall quality (Qts) 0.30
Equiv. air volume (Vas) 19.7 L / 4.15 ft³
